I got an Aerogarden 'Goodful' brand harvest slim at Macy's. On black friday it was $90 for a 6 pod system (then it was $70 the next day >:c).

It's a pretty dumbed-down setup with 6 pods in a row similar to the harvest elite slim model but with the three light display like the harvest/360 model. 3 lights: add food, add water, turn light on/off. It seems that other Aerogarden systems have timers for lights on 6am-10pm and such - is this something where I'll have to turn the lights on and off every day? Will anything be harmed by just leaving the lights on constantly? It's LED lights so I'm not too concerned with the power pull, but would this hurt my herbs?

The innovative AeroGarden Harvest Elite from Miracle-Gro is a wonderful indoor gardening system that grows plants 5 times faster than soil; Easy-to-use control panel creates optimal conditions for your plants by turning the lights on and off and generates a reminder for watering of plants. AeroGarden 6 & 6 LED (New: Fall 2014) Now AeroGarden 6 Classic. Extra and Deluxe (purchased through Spring 2013) Extra Elite and Pro 200. Classic 6 and Classic 6 Elite. Space Saver 6 and Space Saver 6 Elite. 3 and 3 Elite. AeroGarden 3SL. Elite and Pro 100. Veggie Pro and 6 Elite + Harvest/Harvest Elite EU (5 Languages.

The website didn't have any information or guides for this model. Even the printout was pretty general and didn't say anything specific for this display-less model. Like I already put water and food in it and those indicator food/water lights are still on. I emailed aerogarden too, so I'll post in the comments if they get back to me.

8 comments
Size:Download

Your AeroGarden 6 Elite+ has lights and a built-intimer that automatically provide plants with the optimal amount of “sunlight” (about 16 hours) and “night” (about 8 hours), depending on plant type you selected.

As long as plants get this amount of light, it does not matter when lights are turned off.* Many people find it convenient to have lights go on in the morning and off at night to match their own wake and sleep schedule.

*The exceptions to this are Flower & Vegetable plants. They require a daily dark period in order to produce flowers. If your plants will receive any room light during the day (natural or artificial), we recommend setting your AeroGarden lights to be on during the day.

5 Simple Steps..

In order to make this as simple as possible, you only need to set the time you want your AeroGarden

lights to go off (Off Time) and your built-inlight timer automatically sets the On Time..nothing more for you to do.

Do the following to set the time you want your lights to go off:

1Decide what time you want the lights to go OFF.

2AT THAT TIME check that lights are on. If they are off, quickly press “Lights” button and immediately release. (Lights must be on in order to reset timer.)

3With lights on, press and hold “Lights” button until light next to the plant type you selected starts blinking – about 5 seconds.

4Release the button.

5When blinking stops (about 9 seconds), the lights will go off and your lights are now set to go off at this time every day.

You can reset your timer as often as you want.

Herbs

Salad

Flowers

Add Nutrients

Greens

Water Low

Replace

24-Hour

Bulbs

Vegetables

Live Plants

Light

Blinking Light (if you selected Salad Greens)

In case of power failure, your AeroGarden 6 Elite+ has a backup system that stores light, nutrient & replace bulbs timers as well as plant selection settings. When power is restored, your AeroGarden will go back to theOff-Oncycle you have set.

AeroGarden6 Elite+ Control Panel

• Select

• Lights On/Off

The number of hours the lights are on and off depends on which plant type is selected. Use “Select” button to reach “24-Hour Light” setting (see page 9).

Use to occasionally overridebuilt-inlight timer. Once pushed, lights will stay off/on until the next timebuilt-inlight timer is set to go on/off. This will not affect the timing of your light cycle, andoccasional use of this feature will not harm your plants.

Add Nutrients

All files to pdf converter. Replace

Bulbs

• Add Nutrients

(Feed Garden - Basic Feeding)

When “Add Nutrients” and “Water Low” lights start blinking (every 2 weeks), add 2 nutrient tablets* and fill the Bowl with water up to“Fill to Here.” Press and release “Reset” button to restart nutrient timer and turn off blinking lights.

*See Tending & Harvesting Guide forplant-specificnutrient information.

Herbs

Salad

Flowers

Greens

Water Low

24-Hour

Vegetables

Live Plants

Light

• Water Low

When light blinks add water up to

“Fill To Here.”

Manual

• Replace Bulbs

When light blinks (after 6 months of use), it is time to replace Grow Bulbs. Order bulbs atwww.aerogardensupport.com or from your retailer. After replacingGrow Bulbs, press “Reset” button to restart grow bulb timer and turn off flashing light.

NOTE: If you store your AeroGarden 6 Elite+ between uses, grow bulb timer automatically stops when Garden is unplugged.

See complete replacement instructions on next page.

• Remove Bio-Domes

When plants appear through hole in

Seed Pod Label, remove Bio-Domeand discard or recycle.

NOTE: Never remove Seed Pod Labels.

Raise Lamp Hood (Lights)

from lights, raiseLamp Arm one notch at a time (each of the threeLamp Arm sections hasLamp Arm is at the lowest setting when you start your AeroGarden 6 Elite+.

1Unplug AeroGarden 6 Elite+ and remove Bowl fromBase.

2Raise Lamp Arm/Lamp Hood:

Hold Lamp Arm where it connects toLamp Hood with one hand. With other hand, push inLocking Lever.

Release Locking Lever while pulling up onLamp Arm.

Locking Lever will automatically click into next notch in theLamp Arm section.

3Replace Bowl onBase and plug in AeroGarden 6 Elite+.

Push Locking

Lever in

Push Locking

Lever in

Push Locking

Push Locking

Lever in

Lever in

Replace Grow Bulbs – Order bulbs at www.aerogardensupport.com

When “Replace Bulbs” light on Control Panel begins blinking after 6 months of use…

Unplug AeroGarden 6 Elite+.

Remove old Grow Bulbs and carefully discard.*

IMPORTANT: To avoid burning, be sureGrow Bulbs are cool before handling.

Insert new Grow Bulbsinto Lamp Hood.

Plug in AeroGarden 6 Elite+ and press and release “Reset” button to restart grow bulb timer.

Early Grow Bulb Replacement

If you replace Grow Bulbs before “Replace Bulbs” light illuminates, be sure to restart grow bulb timer as follows:

Press and hold “Lights” button until light next to your selected plant type starts blinking – about 5 seconds.

Release “Lights” button. The plant type selected light will continue to blink for about 9 seconds. While plant light is still blinking…

Quickly press and release “Reset” button. “Replace Bulbs” light will blink once and the plant selected light will stop blinking.

*Check with local recycling authorities for light bulb recycling availability in your area.

Basic Reminders About Your AeroGarden (continued)

(Optional) Trellis System

About the Trellis System(not included)

Your AeroGarden 6 Elite+ has the option of connecting a Trellis System to itsLamp Hood. TheTrellis System

allows you to easily support heavy, fruit-filledbranches onfull-sizeplants such as tomatoes, peppers and cucumbers.

If you are interested in purchasing an AeroGarden Trellis System, you may do so atwww.aerogardensupport.com or from your retailer.

Trellis System installation

If your AeroGarden 6 Elite+ is already assembled, you will need to remove the Lamp Hood fromLamp Arm, and removeGrow Bulbs from theLamp Hood before starting.It is best to do this when Garden lights are off.

Unplug AeroGarden 6 Elite+ and carefully remove Lamp Hood fromLamp Arm.

Turn Lamp Hood over and remove Grow Bulbs. (Be sure bulbs are cool before handling.)

Attach Trellis Bracketsto Lamp Hood

Hand tighten pre-mountedscrews with phillips head screwdriver.Do not over-tighten.

Insert Grow Bulbsinto Lamp Hood.

Replace Lamp Hood onLamp Arm and plug in AeroGarden 6 Elite+.

Use Trellis System

1 Clip Trellis Coilon Bracket.

2 Pull down Trellis Coil.

Lamp Hood

Bracket

Trellis Coil

3Wrap Strap around branch that needs support and snap closed.

As a safety precaution, unplug AeroGarden furnishing before performing this task. Be sure Grow Bulbs are cool to the touch before attaching or adjustingTrellis Coil.

13

4Gently push up on supported branch until it is at desired height.

Cleaning Instructions for your AeroGarden

Use only water and mild soap when cleaning your AeroGarden (except when Sanitizing - Step 6). Do not use abrasive cleaners or run through the dishwasher.

When your garden has completed its growing cycle…

Elite

1Unplug AeroGarden.

2Carefully remove Bowl andGrow Surface fromBase and bring to

a sink. Set Base andLamp Hood aside. Fancy pants man adventure 3 unblocked.

NEVER SUBMERSE BASE AND

CONTROL PANEL IN WATER.

3Remove Grow Surfacefrom Bowland place on a counter near a sink.

4Empty contents of Bowl in sink.

5Remove Seed Pods and plants fromGrow Surface.

Pull Seed Pods out ofGrow Surface openings.

Throw away Seed Pods and plant debris (plant growth and roots). If you compost, plant debris can be composted.

6Sanitize AeroGarden.

Fill Bowl ¾ full with water.

Add ¼ cup (59ml) of chlorine bleach.

Let sit for 2 minutes.

Using sanitizing water, wipe

Grow Surface and Bowlwith soft cloth or sponge.*

The 6.2.0.403 version of Movie Magic Scheduling is provided as a free download on our software library. This software is an intellectual property of Entertainment Partners. The software is included in Multimedia Tools. The most popular versions among Movie Magic Scheduling users are 5.2, 4.2 and 4.1. Ep movie magic scheduling.

*Gloves recommended.

Scrub underside of Grow Surface with soft scrub brush to remove any tangled roots.

Empty bleach water from Bowl.

7Rinse Bowland Grow Surfacewith tap water. Repeat.

8Towel dry Bowland Grow Surfacebefore putting them back together and setting them on Base.

9If Grow Bulbs have been in use more than 6 months, they should be replaced at this time (see page 12).

Your AeroGarden is now ready for replanting.

14

Prepare For Your Next Garden (continued)

Replanting Your AeroGarden

If you have already grown a garden in your AeroGarden 6 Elite+, please follow the instructions below to reset the nutrient timer:

Press and hold “Reset” button until red “Add Nutrients” light blinks 3 or 4 times (about 9 seconds).

Release “Reset” button. “Add Nutrients” light will turn off.

Aerogarden manual download

Your AeroGarden is now reset. (In some cases you may see other lights blink as well. This is nothing to worry about.)

NOTE: These steps do not reset grow bulb timer.

Herbs

Salad

Flowers

Add Nutrients

Greens

Water Low

Replace

24-Hour

Bulbs

Vegetables

Live Plants

Light

Reset

Add Nutrients

! Bundle cord when furnishing is not in use.

U.S. CAUTION You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna; Increase the separation between the equipment and receiver; Connect the equipment into an outlet on a circuit different from that to which the receiver is connected; or, Consult the dealer or an experienced radio/TV technician for help.

To reduce the risk of electric shock, this furnishing has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

Aerogarden Elite Manual Transmission

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Aerogarden 6 Manual Pdf

ATTENTION: POUR ÉVITER UN CHOC ÉLECTRIQUE, PRÉSENTER LA LAME LARGE À LA FENTE LARGE ET POUSSER JUSQU’AU FOND.

Aerogarden Elite Manual

© 2008 AeroGrow International, Inc., Boulder, CO U.S.A. U.S. Patents Pending
